Rea Azalea Tilt in Space Manual Wheelchair

The Invacare Rea Azalea tilt-in space wheelchair is one of our bestselling chairs offering postural support and comfort. The Rea Azalea is available in a range of wheelchair models.  Each chair is highly configurable and can be easily adjusted if client conditions change. The chair comes with a tilt and recline seating system that allows you to adjust the position of the seat and maintain comfort at all times.

The Rea Azalea passive wheelchair is the go-to choice for controlling postural support and comfort. It also comes with the Invacare Dual Stability System (DSS).

Rea Azalea Manual wheelchair Backrests
Rea Azalea Max Manual Wheelchair
Rea Azalea Max Manual Wheelchair
Manual wheelchair Rea Azalea minor - small adults teenagers
Rea Azalea Manual wheelchair Backrests
Rea Azalea Max Manual Wheelchair
Rea Azalea Max Manual Wheelchair
Manual wheelchair Rea Azalea minor - small adults teenagers
Rea Azalea Manual wheelchair Backrests
Rea Azalea Max Manual Wheelchair
Rea Azalea Max Manual Wheelchair
Manual wheelchair Rea Azalea minor - small adults teenagers

Key features include:

  • Flex 3, backrest plate: Comes with a flex 3, backrest plate that is sturdy and provides support, with both width and height adjustment. The users also get to pick between a wide range of cushions suitable for their comfort.
  • A Flex 3, tension adjustable backrest: The Flex 3, tension adjustable backrest is built to accommodate more complicated spinal shapes. This feature also offers several other adjustments that can suit both the female and male body and several shapes and sizes.
  • Wide range of wheelchair accessories: Adding to the multiple adjustments in the chair, the Rea Azalea also offers a large variety of options and accessories that guarantee a solution for a wide range of postural challenges.
  • 24-degree seat tilt and a 30-degree backrest recline: It also features a 24-degree seat tilt and a 30-degree backrest recline to support a range of positioning requirements.
  • DDS: Equipped with a Dual Stability System for added safety and confidence
  • Transit wheels: For attendant propulsion or self-propel wheels for the moderately active individual.


The Invacare Rea Azalea wheelchair is a HSE tender awarded product.

Excellent seating comfort and many adjustment possibilities
Excellent seating comfort and many adjustment possibilities
The comfortable seating system allows the patient to alter the seat positioning, ensuring maximum comfort at all times, thus combined with excellent driving characteristics make Azalea the ideal choice.
Better tilt and recline patient experience
Better tilt and recline patient experience
The Rea Azalea and Rea Azalea Assist have a 25° seat tilt and a 30° backrest recline contributing to improve the quality of life of the patient. Both tilt and recline can be easily modified manually or electronically by the assistant and also by the client using the electrical option.
Comfortable and safe resting position.
Comfortable and safe resting position.
Weight shifting maintains the wheelchair stability no matter which seat angle the chair is.
An adaptative and evolutive T/R chair
An adaptative and evolutive T/R chair
The large choice of accessories of Rea Azalea allows the chair to bring appropriate support solutions depending on the patient disease evolution along the patient`s life.
Individualized support of the patient¿s back by the Flex 3 tension adjustable backrest
Individualized support of the patient¿s back by the Flex 3 tension adjustable backrest
The Flex 3 tension adjustable backrest has height and width adjustability. Also,it is possible to angle the backrest posts outwards, and you could rotate the backrest upside down depending on where you needed more space such as the shoulders or the bottom.

Request a quote

Please complete the below form to request a quote. Please note, personal data you provide will not be used or stored unless you would like to stay connected. For more information, view our Privacy Policy that can be found at the bottom of this page.

By submitting my information, I acknowledge that I have read and understand Invacare's privacy notice.
Specifications & Downloads
Technical data
Technical data
Seat width

Seat width

390-440 / 440-490 / 490-540 (390-490 / 440-540 / 490-590 mm)

Seat depth

Seat depth

430 - 500 mm

Seat angle

Seat angle

-1° to 23° (+1° to 25°)

Seat height

Seat height

400 / 450 mm

Backrest angle

Backrest angle

0° - 30°

Backrest height

Backrest height

Backrest plate: 560-790 mm / Tension adjustable backrest: 540-715 mm

Length of footrests

Length of footrests

330 - 500 mm

Armrest height

Armrest height

240 - 360 mm

Driving unit width

Driving unit width

SW + 220 mm (SW + 230 mm)

Total length inc. footrests

Total length inc. footrests

950 - 1020 mm

Total height

Total height

900-1250 mm

Max. safe slope

Max. safe slope

Max. User weight

Max. User weight

Max 135 kg

Total weight

Total weight

34 kg (SW 440 mm)

Transport weight

Transport weight

16.5 kg

Crash tested

Crash tested

Frame colour

Frame colour

Pearl Grey, Azurite Blue, Sand, Happy Red, Electric Green

Colour (other)

Colour (other)

Black Dartex TR26, Black plush TR35, Black spacer TR36

Comment

1. Transport weight increases with 4.2 Kg when the E-tilt & Recline option is used
